"Turn the Corner" TIG Welding
Instructor: Roy Crumrine • 22m
Roy "Crummy" Crumrine walks us thru "Turn the Corner" TIG Welding on Aluminum where tig torch and filler rod angles are "whatever it takes"
Settings and Details
WELD PROCESS = TIG, GTAW, GAS TUNGSTEN ARC WELDING
METAL TYPE = ALUMINUM
THICKNESS = 1/8"
WELD TYPE = FILLET WELD
JOINT TYPE = TEE
POSITION = 2F HORIZONTAL
AMPERAGE = 120-135 CONTROLLED WITH FOOT PEDAL
TUNGSTEN = 2% LANTHANATED, 3/32"
FILLER WIRE = 3/32” 4043
POLARITY = AC
GAS FLOW = 15-18 CFH argon
CUP SIZE = 5 STANDARD COLLET BODY
ADDITIONAL SETTINGS = AC BALANCE 27% CLEANING, AC FREQ 170HZ
FRONIUS WAVEFORM SETTINGS = Waveform Positive Rectangle Hard,
Waveform Negative Triangle
0 Offset
PRE FLOW = 1 SEC
POST FLOW = 10 SEC
